Nagasaki - ML-800 - Hydraulic Jack
Features
To meet the demand for a more efficient working with two-paul and fourpaul lift, our ML-800, Hydraulic Transmission Lift has been specially designed to provide the high standard of efficiency for the service of ordinary cars. Movable to all direction with ease. Light-weighted finish giving smoothness on servicing.
1. Equipped with handle, you can move it easily to all direction.
2. Table (Attachment) are designed to move back and forth also right and left.
3. Foot-pedal pump assuring easy lifting.
4. Ram, Pump and Piston are specially finished to prevent oil leakage.
5. Urethan wheel assures smooth movement and avoids squeaking.
6. Can be operated in a pitted workshop.
| SPECIFICATION | |
| Full length | 800 mm |
| Full width | 850 mm |
| Minimum height | 900 mm |
| Middle height | 1,330 mm |
| Maximum height | 1,800 mm |
| Power lift | 900 mm |
| Table cradle (Forward and Backward tilt) | 15° |
| Sidewise slide | 40 mm |
| Oil capacity | about 1.8 / |
| Rated capacity | 800 kg |
| Net weight | 75 kg |
| For minature cars-ordinary cars | |
