ALTECH - PMS-30 - Full Rise Scissor Lift
PMS30 flush mount scissor lift with control cabinet. 3000kg lifting capacity with Hydraulic power system, dual synchronous cylinders, extendable
platforms, automatic safety device, and mechanical safety locks. Includes stop switch ground and alarm tone when coming down to the ground.
- Pneumatic Lock Release
- Electromagnetic Lowering
SAFETY FEATURES
- Precision machined safety lock
- Safety descending stop & alarm
- Safety valve for anti-explosion of hydraulic system
- Height limit switch
- EVA Rubber mat (4pcs/set)
| TECHNICAL DATA | |
| Capacity | 3.0 T |
| Lifting Height | 2050 mm (80 inch) |
| Min height | 330 mm (13" inch) |
| Platform length | 1450 mm (57" inch) -- 1750 mm (68 9/10" inch) |
| Power supply | 220V 1PH 50/60Hz 2.2KW, 220/380V 3PH 50/60Hz 2.2KW |
