Onodani - PP-11FW - Four Post Parking Lift
DESCRIPTION
- It is the ideal parking garage for vehicles, with a maximum lift of 1971mm and a lifting capacity of 11,000lbs
- Manual safety mechanism and cable breaking protection mechanism, double safety mechanism, safer.
- Use high density slider, long service life.
- Explosion-proof throttle valve on tubing can prevent tubing from bursting and falling rapidly.
- Integral forming of platform with high strength anti-skid plate.
- Special brake block to prevent vehicle from moving.
- Four cars can be parked at the same time to save space.
| TECHNICAL PARAMETER | |
| Model | PP-11FW |
| LxWxH | 5632*5030.5*2312mm |
| Max. Lifting Height | 1971mm |
| LiftingTime | 50s |
| Width Between Columns | 4655.5mm |
| Overall Length | 5632mm |
| Overall Width | 5030.5mm |
| Platform Length | 4200mm |
| Lifting Capacity | 11000LBS |
| Runway Width | 475mm |
| Width Between Runway | 955mm |
| Packing Size1 | 4270*560*730mm |
| Packing Size2 | 5000*560*560mm |
| Gross Weight1 | 915KG |
| Gross Weight2 | 1045KG |
