Onodani - CUT4011 - Inverter Air Plasma Cutter
Features
- IGBT inverter technology.
- Compact size, light weight, high efficiency and energy saving.
- ABS plastic enclosure with excellent insulation performance and corrosion resistance.
- Cutting speed is much faster than oxyfuel cutting by up to 1.8 times.
- Thick metal plate can be cut easily, quickly and economically.
- Suitable for cutting stainless steel, copper, carbon steel, aluminium etc.
- Simple operation, smooth cutting surface.
- HF arc starting with contact.
- Built-in over current and overheat protections offer extreme reliability andsafety
| TECHNICAL DATA | |
| Input voltage ± 10% | 220V 50/60Hz 1-ph |
| Rate input power | 30A |
| No-load voltage | 230V |
| Output current range | 15-40A |
| Rated output voltage | 94V |
| Duty cycle | 35% |
| Efficiency | 80% |
| Power factor | 0.93C0S Ø |
| Insulation grade | B |
| Protection grade | IP23 |
| Arc starting | Contact |
| Gas flow | 0.17 m3/min |
| No-load loss | 60W |
| Max cutting thickness | 12mm |
| Overall Dimensions | 410x165x260mm |
| Weight | 8kg |
