Giuliano - S 110 - Swing-Arm Tyre Changer
FUNCTIONS
- Robust vertical tower swinging horizontal arm with Ø 41mm operating arm
- Bead breaker double effect Cylinder Ø 200mm
- Reinforced Chassy
- Tabletop thickness 12mm
- Fitting head designed for both standard and low profiled tire applications
- Tire inflating by pedal (optional)
- Suitable for Press Arm (optional)
- Suitable for Tubeless tire bead seating system (optional)
- “Easy Access” extractable pedal box for quick service
| STANDARD FEATURES | |
| Rim clamping from outside | 10" - 22" |
| Rim clamping from inside | 12" - 24" |
| Max. tyre diameter | 1100 mm (43") |
| Max. tyre width | 330 mm (13") |
| Bead loosener cylinder force at 10 Bar | 30800 N |
| Operating pressure | 10 Bar (145 Psi) |
| Power supply | 400V - 3ph, 220V - 1ph |
| Motor power | 0,55 kW (3ph) |
| Rotation speed | 7 rpm |
| Pre-set tyre inflating pressure | 3,5 Bar (50 Psi) |
| Net weight | 190 kg |
