Giuliano - S 225 - Automatic Tilt Back Tyre Changer
FUNCTIONS
- Tilting tower, sliding horizontal arm with Ø 41 mm operating arm.
- Bead breaker double effect Cylinder Ø 200 mm.
- Reinforced Chassis.
- Tabletop thickness 12 mm.
- Fitting head designed for both standard and low profiled tyre applications.
| STANDARD FEATURES | |
| Rim clamping from outside | 10" - 22" * |
| Rim clamping from inside | 12" - 24" * |
| Max. tyre diameter | 1010 mm (39") |
| Max. tyre width | 390 mm (15") |
| Bead breaker cylinder force at 10 Bar | 30800 N |
| Operating pressure | 10 Bar (145 Psi) |
| Power supply | 400V - 3ph, 220V - 1ph |
| Motor power | 0,55 kW (3ph) |
| Rotation speed | 7 rpm |
| Pre-set tyre inflating pressure | 3,5 Bar (50 Psi) |
| Net weight | 310 kg |
* By adjustable jaws
