KTC - ABX70 - Brake Bleeder
Purpose
- Replacing brake oil and supplying of brake oil during air-removing.
Application
- Applicable to reserve tanks (inner diameter of inlet: Ø 18-76) for mini cars and compact cars to small trucks (2t).
Features
- Continuous feeling (pressured) shortens work time
- Compact design: simple, low cost, but high performance.
- Easy to operate for air-driven method.
- One touch on the button enables air-removing of the tank.
- Plate rubber adopted for attachment by one action (see attachment A1).
- Expansion rubber with inner pressure ensures excellent contact (see attachments A2, B1 and B2).
| SPECIFICATION | ||
| Hose Outer Diameter | 8.8 mm | |
| Hose Inside-Diameter | 5.5 mm | |
| Tank Capacity | 2 L | |
| Feeding Hose | 3.5 m | |
| Body Dimensions | 320(L) × 205(W) × 210(H) mm | |
| Weight | 8.5 Kg | |
| Set Contents | Brake bleeder body (with dust cover) | |
| Attachment A1 | A1ABX70-A1 | |
| Attachment A2 | ABX70-A2 | |
| Attachment B1 | ABX70-B1 | |
| Attachment B2 | ABX70-B2 | |
| Clamp D1 (Claw) | ABX70-D1 | |
| Clamp E1 (Chain) | ABX70-E1 | |
| Attachment Case | Pastic Case | |
