Onodani - HC-3285A - Mobile Waste Oil Suction
- Exclusive patented self-explosion-protect device.
- Be equipped with a transparent chamber to observe the waste oil before ectract into the tank.
- Be equipped with a ball valve for the oil tray to inspect waste oil before entering the tank.
| PARAMETERS | |
| Air Inlet Pressure(bar/psi) | 6~8/87~116 |
| Air Inlet Connection(inch) | 1/4” |
| Vacuum Degree(bar) | -1~0 |
| Air Pressure for Oil Discharge(bar/psi) | 0.7 ~ 1/10 ~ 14 |
| Suction Speed@Probe dia. Ø8 & Oil 60OC(Liter/m/US Gallon/m) | 6.5/1.72 |
| N.W./G.W.(kgs) | 46/50 |
| Tank Package Dimension(mm) | 570*540*1020 |
| Support Frame Package Dimension (mm) | 1310*100*80 |
| Tray Package Dimension | 735*635*225 |
