CORGHI - EXACT LINEAR - Wheel Alignment
ENTRY LEVEL PRICING
Entry level pricing with top range specifications, small investment with a big turnover. Wheel alignment for everyone
- Fast
- Easy
- Precise
- Reliable
- Complete
- Quality at affordable prices
USER FRIENDLY
- Corghi Icon user friendly graphics.
- Simple and efficient easy to learn, fast to select
HIGH RESOLUTION TARGET
- Unique High resolution 80 x 80 and 80 x 90 target board
HIGH QUALITY CAMERA
-
Next generation camera with high resolution HiQ lenses
ERGONOMIC WORKTOP
- New designed worktop with plenty of space for all your working tools
TROLLEY
- Practical trolley for clamp and sensore holder (optional)
CAMERA MOVEMENT KIT
-
Camera movement kit alows the operator to work from pit level to over 2.00 meters by pressing a keyon the keyboard.
-
Fast and easy
DRIVE ON ASSISTANT
- Drive on assistant for safe manouvering in the workshop without additional operator or mirror. With double view.
| TECHNICAL DATA | |
| Measuring ranges | |
| Total toe | ± 20° |
| Half toe | ± 10° |
| Camber | ± 10° |
| Caster | ± 30° |
| King pin | ± 30° |
| Set back | ± 22° |
| Thrust angle | ± 10° |
| Steering difference at | ± 20° |
| Power supply | |
| Power supply voltage | 115-230 Vac 50-60 Hz 1ph |
| Power absorption | 500 W |
| Pc Holder | 11 kg |
| Camera beam | 26 kg |
| Column | 66 kg |
